TR-72C Tamper Rammer
> > >

Features 1. The TR-72C tamper rammer is driven by a 4-stroke engine that delivers outstanding operational performance.
2. A throttle lever includes the rack and pinion unit that allows for more reliable functioning and longer use life.
3. Corrosion-resistant oil tank is made of high-density polyethylene. It is rust-free.
4. Double air cleaner system traps over 99% of airborne dirt, providing cleaner air for longer use life.
5. Independently design bellow has been tested for over 1 million times. It provides more accurate coefficient of contraction.
6. Shock-absorbing kickback is made of rubber, reducing the vibration felt by operators and giving operation comfort.
7. The base plate, also known as foot, is made of laminated wood and steel. It absorbs shock and stress

Technical Data
Model TR-72C
Pounding Frequency(time/min) 680-710
Engine Robin EH12-2D
Engine Type Air-cooled, 4-Stroke, single-cylinder, OHV, P.O.T.
Displacement(ml) 121
Max. Power 2.9Kw/4000rpm
Rated Power: 2.6Kw/4000rpm
Bore x Stroke(mm): 60×43
Condensation Ratio 8.0
Starting System Recoil Starter
Ignition System TCI
Fuel Tank Capacity(L) 2.5
Lube Oil Capacity(L) 0.55
Jumping Stoke(mm) 65-80
Advance Speed(m/min) 10/15
Rammer Plate Dimension(mm) 340×285/340× 300
Impact Force (KN) 15
Dimensions L×W×H (mm) 720×415×1043
Packing size L×W×H (mm) 1100×750×460
Net Weight (kg) 72
Gross Weight (kg) 81
Quantity/Container 75pcs/20'GP 160pcs/40'HQ
Optional Engine Honda GX100

Related Names
Jumping Jack Compactor | Ground Tamper | Impact Rammer
